3 CNC SWISS TSUGAMI MORI BS32C-III – 2005 – EMBARREUR IEMCA


  • 3 tours à poupée mobile
  • Marque : Tsugami
  • Modèle : BS32C-II
  • 32mm
  • 2005
  • C Axis:
  • Y Axis:
  • Live Tooling
    Spécifications
    Bar feed interface
    part récuperator spindle 1 and 2
    indicator signal
    spindle 2 indexing every 5°.
    rigid tapping
    coolant through the spindle
    Max Bar Diameter 1.25″ (25 mm)
    TRAVELS (courses) :
    Z1 9.75″ (228 mm)
    T1 11.6″ (279 mm)
    X1 2.28″ (50 mm)
    X2 8.66″ (203 mm)
    Z2 7.88″ (177 mm)
    Main Sindle Speed 200 – 7,000 RPM
    Sub Spindle Speed 200 – 6,000 RPM
    Main Spindle HP 7.5 HP
    Sub Spindle HP 2.7 HP
    Number of Stations 6 OD, 5 ID/OD Fixed BW Tools
    Cross Driven Tools 2 Drive B/W 5/8″ Square
    Dimensions 88″ x 60″ x 84″ H (2235 x 1524 x 2133 mm)
    IEMCA Boss 545 Bar Feed Included
    7,000 RPM Main Spindle
    Full C Axis
    9.84″ Max. Machining Length (228 mm)
    1.25″ Machining Dia. (25 mm)
    1.25″ Max. Bar Capacity (25 mm)
    6,000 RPM Back Spindle
    20 Tool Capacity
    price ex VAT on request
    machine available unless sold in the meantime


PRIX : Contactez-nous
